Shelly Pro 3EM Switch Add-On
19.00 JOD
Add-on for Shelly Pro 3EM
A galvanically isolated switch designed to expand the capabilities of your Shelly Pro 3EM device. This add-on allows you to easily control contactors and other electrical devices, giving you greater flexibility and control over your consumption.
- Dry contacts
- DIN-rail mountable
*Only compatible with Shelly Pro 3EM!
Endless Use Applications
Use Cases
Load shedding
Keep track of how much energy your solar panels and wind turbines are generating and save effortlessly by controlling your consumption with Shelly Pro 3EM Add-on. Connect Shelly Pro Add-On to your appliances and use Shelly Pro 3EM’s real-time information on how much energy has been generated and consumed. When you need to save energy, Shelly Pro3EM Add-on can automatically switch off non-essential appliances in your home.
Use Cases
Weather-based control
Shelly Pro 3EM, enhanced with the Shelly Pro 3EM Add-on, offers weather-driven energy optimization. By scripting, you can efficiently control your appliances based on the weather forecast. Upon receiving real-time weather updates, Shelly Pro 3EM takes measures as defined in the script. For example, if the forecast indicates that it’s going to be a sunny day, Shelly Pro 3EM Add-On can automatically turn off the heating anticipating higher temperatures.
Use Cases
PV systems balancing
When your PV system is producing more energy than your home consumes, Shelly Pro 3EM Add-On can automatically activate appliances to make use of it. For example, you can set it to turn on your water heater, charging station for electric vehicles, or other energy-intensive appliances. This way, you make the most of the abundant energy generated by your PV system and reduce dependency on the grid.
Full compatibility
Full compatibility
smart home control, perfected
shelly smart control
Get the app on:
Shelly Smart Control –
one app to control your spaces, energy consumption, and expenses.
Shelly Smart Control –
one app to control your spaces, energy consumption, and expenses.
Get the app on:
specifications
| Physical | |
|---|---|
| Size (HxWxD): | 94x19x69 ±0.5 mm / 3.70×0.75×2.71 ±0.02 in |
| Weight: | 20 ±1 g / 0.70 ±0.05 oz |
| Mounting: | DIN rail, attached to a Shelly Pro 3EM |
| Screw terminals max torque: | 0.4 Nm / 4.43 lbin |
| Conductor cross section: | 0.5 to 2.5 mm² / 20 to 14 AWG (solid, stranded and bootlace lugs) |
| Conductor stripped length: | 6 to 7 mm / 0.24 to 0.28 in |
| Shell material: | Plastic |
| Color: | White |
| Environmental | |
| Ambient temperature: | -20 °C to 40 °C / -5 °F to 105 °F |
| Humidity: | 30 % to 70 % RH |
| Max. altitude: | 2000 m / 6562 ft |
| Electrical | |
| Power supply voltage AC: | N/A |
| Power supply voltage DC: | 3.3 V and 12 V (from Shelly Pro 3EM device) |
| Power consumption: | < 1 W |
| Output circuits ratings | |
| Max switching voltage AC: | 240 V |
| Max switching voltage DC: | 30V |
| Max switching current AC: | 2A |
| Max switching current DC: | 2A |
