Shelly Dimmer2
28.00 JOD
Wi-Fi operated relay with dimming function and no neutral line
- Supported light types – Incandescent and halogen light sources 1-220W, Dimmable LED 50-200VA/10W – 200W, Resistive-inductive loads ferromagnetic transformers 50-150VA
- Overload and temperature protection
- Designed for installation in a limited space, such as wall mounts, electrical control panels, etc.
- Easy control through the Shelly app, as well as various protocols, platforms, and voice assistants.
- Has an embedded web server and connects to your Wi-Fi network
**The colors of the wires can differ depending on your electrical installation or local wiring standards. Please see the knowledge base or user guide for the proper wiring diagram of the device.
Why Shelly Dimmer 2?
Smart Wi-Fi dimmer for all electrical installations
Shelly Dimmer2 is a smart switch unit for luminous intensity adjustment with precise power metering that can fit into all electrical installations. It provides a full set of dimming functionalities and can be used even in houses where the neutral line is missing. Use it to control, dim, and power measure a wide range of halogen lights, dimmable LED, and ferromagnetic transformers between 110-230V ±10%.
Functionalities
Wi-Fi operated
Connect Shelly Dimmer2 to your Wi-Fi network. No HUB required!
No neutral required
Shelly Dimmer2 doesn’t require a neutral line to provide a full set of dimming functionalities.
Power Monitoring
Shelly Dimmer2 provides precise monitoring of power consumption.
Light intensity adjustment
Use the dimming function to set the brightness of your lights to your preference.
Smart schedules
Set custom schedules based on your daily agenda or follow the sunrise/sunset and control your lighting accordingly.
Smart scenes
Set custom scenes by combining Shelly Dimmer2 with your other Shelly devices.
Endless Use Applications
Use Cases
Brightness that suits your activities
Depending on your activities and the time of day, different types of light and luminosity are suitable. With Shelly Dimmer2, you can adjust the brightness according to your preference and set the most perfect lighting level for reading bedtime stories, watching TV, having dinner, etc. For further customization, use the smart schedules function to set a beginning hour for each activity. That way, once the lights in the children’s room dim, they will know it is bedtime.
Use Cases
Control the lights based on the luminosity
Don’t lose the bright light at home when the weather is gloomy and rainy! Thanks to its LUX sensor, Shelly Door/Window2 can be adjusted to follow the natural light outside and switch on the lights earlier on rainy days, slowly increasing the brightness as the afternoon turns into evening.
Set the mood for "Movie night"
Create your own “Movie scene” with Shelly and treat yourself to a real movie theater experience. Set Shelly to turn on the projector, dim the lights, and shut down the blinds. Now you can enjoy your favorite comedy, horror movie, or thriller in comfort and privacy. For additional comfort, combine Shelly with your preferred voice assistant and simply say “Turn on the Movie routine!”
Recommended
Use Cases
"Night mode" for soft night light
Walking to the bathroom at night could no longer be irritating to your sleepy eyes. Shelly Dimmer2 has a “Night mode” functionality, setting the lights brightness at a low level during the night hours. Now when the lights are turned on manually, through voice, or by a motion sensor, they will always be dimmed and soft.
Full compatibility
Full compatibility
smart home control, perfected
shelly smart control
Get the app on:
Shelly Smart Control –
one app to control your spaces, energy consumption, and expenses.
Shelly Smart Control –
one app to control your spaces, energy consumption, and expenses.
Get the app on:
specifications
| POWER | |
|---|---|
| Power supply AC | 110-230V ±10%, 50/60Hz |
| SPECIAL FUNCTIONS | |
| Device temperature protection | Yes; 95°C |
| Overload protection | Yes |
| Power measurement | Yes |
| Dimming | Yes |
| Dimmable LED | 50-200VA / 10W – 200W |
| Incandescent and halogen light sources | 10-220W |
| Working without a neutral line | Yes |
| FEATURES | |
| Colour changing | No |
| Predefined effects | Yes |
| Channels | 1 Channel |
| Operational temperature | 0 to 40°C |
| Device power consumption | < 1 W |
| Intelligent On/Off | Yes |
| Local and remote control | Yes |
| Sunrise/Sunset | Yes |
| Weekly Schedule | Yes |
| UL Listed option | No |
| CONNECTIVITY | |
| Wireless/WiFi Protocol | 802.11 b/g/n |
| Radiofrequency | 2400 – 2500 MHz |
| Range | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
| DIMENSIONS | |
| Size | 42mm x 36mm x 14 mm |
