Shelly Dimmer 0/1-10V PM Gen3
20.00 JOD
Wi-Fi operated smart dimming controller with power measurement
Designed to manage 0/1-10V dimming drivers, Shelly Dimmer 0/1-10V PM Gen3 offers precise dimming with power measurement. It is retrofit and can be used with any regular switch you have at home.
- Supports 0-10V and 1-10V types of drivers (lights, motors, valves, etc.
- Wi-Fi and Bluetooth-operated
- Shelly Plus Add-On compatible: Supports connection with the sensor interface to measure different data (humidity, temperature, etc)
- One/dual button dimming mode (use with physical switches)
- Customizable thresholds and offsets for temperature, humidity and light if used with Plus Add-on
- Power measurement: Precise monitoring of energy consumption. Information about voltage (V), current (A) and consumption (W) is displayed.
- Safety: Оver current/voltage/power protections
- Supports “Night mode”: Automatically sets the lights’ brightness at a low level during the night hours
- Wi-Fi Range Extender & BLE Gateway
- Equipped with a new processor & increased flash memory – ESP Shelly
- No hub required! Easy control through the Shelly Smart Control app, most platforms and protocols, as well as voice assistants. Use it with Alexa, Home Assistant, or your preferred automation platform.
Why Shelly Shelly Dimmer 0/10V PM Gen3?
Use it with your existing switches!
Use your favorite style and brand of switches and seamlessly integrate dimming capabilities into your current setup.
Functionalities
Wi-Fi operated
Connect Shelly Dimmer 0/1-10V PM Gen3 to your Wi-Fi network. No HUB required!
Bluetooth
Quick inclusion via Bluetooth or use it as a Bluetooth gateway.
Power monitoring
Provides precise monitoring of power consumption and free data storage.
Flexible input control
Use it with your existing switches, no matter if they’re single or dual button.
Smart scenes
Set custom scenes by combining Shelly Dimmer 0/1-10V PM Gen3 with your other Shelly devices.
Smart schedules
Set custom schedules based on your daily agenda, or follow the sunrise/sunset and control your lighting accordingly.
Use Cases
Track your power consumption and save money
Shelly Dimmer 0/10V PM Gen3 has an integrated precise power meter. By continuously monitoring and reporting real-time power consumption, it helps you identify which lighting setups are the most energy-efficient, enabling you to make informed decisions that optimize energy use. Over time, this can lead to substantial energy savings and a noticeable reduction in your utility costs. Whether you’re automating your lights to dim when not needed or scheduling them to adjust according to natural light conditions, Shelly Dimmer 0/10V PM Gen3 is your key to a smarter, greener home.
Set the mood instantly
Shelly Dimmer 0/1-10V PM Gen3 doesn’t stop at schedules- it embraces moments too. With its pre-set lighting scenes, a simple voice command can transform your room. Feel like watching a movie? Just tell Alexa, “Movie night,” and your space instantly adapts, casting the perfect ambiance for your cinematic experience.
Track your power consumption and save money
Shelly Dimmer 0/10V PM Gen3 has an integrated precise power meter. By continuously monitoring and reporting real-time power consumption, it helps you identify which lighting setups are the most energy-efficient, enabling you to make informed decisions that optimize energy use. Over time, this can lead to substantial energy savings and a noticeable reduction in your utility costs. Whether you’re automating your lights to dim when not needed or scheduling them to adjust according to natural light conditions, Shelly Dimmer 0/10V PM Gen3 is your key to a smarter, greener home.
Set the mood instantly
Shelly Dimmer 0/1-10V PM Gen3 doesn’t stop at schedules- it embraces moments too. With its pre-set lighting scenes, a simple voice command can transform your room. Feel like watching a movie? Just tell Alexa, “Movie night,” and your space instantly adapts, casting the perfect ambiance for your cinematic experience.
Gen3 Series features
On the Road to Matter
Each Gen3 device is engineered to be upgradable to Matter. The doubled memory, compared to Plus series, guarantees a smooth update process, paving the way for new smart capabilities and integrations.
*Dependent on the extent of Matter’s functionalities support.
More Memory, More Power
The Gen3 series ensures the quality and reliability of our devices by using our own powerful Shelly chip. Boasting 8MB of memory, this dramatically improves device performance and efficiency. This significant increase in memory not only guarantees smoother and faster operation but also equips the Gen3 series for the introduction of new capabilities.
Unified Control with Virtual Components
The Gen3 Series introduces “virtual components, transforming how you manage and control 3rd party devices. Within the Shelly Smart Control app, you can now create virtual devices, integrating non-Shelly products into a unified control system. This feature provides streamlined control of all your smart devices, regardless of brand, from a single interface.
Full compatibility
Full compatibility
smart home control, perfected
shelly smart control
Get the app on:
Shelly Smart Control –
one app to control your spaces, energy consumption, and expenses.
Shelly Smart Control –
one app to control your spaces, energy consumption, and expenses.
Get the app on:
specifications
| Physical | |
|---|---|
| Size (HxWxD): | 38.5×43.5x17mm / 1.52×1.71×0.67in |
| Weight: | 28.5 g / 0.99 oz |
| Screw terminals max torque: | 0.4 Nm / 3.5 lbin |
| Conductor cross section: | 0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length: | 5 to 6 mm / 0.20 to 0.24 in |
| Mounting: | Wall console/behind wall/ceiling construction |
| Shell material: | Plastic |
| Environmental | |
| Ambient working temperature: | -20°C to 40°C / -5°F to 105°F |
| Humidity: | 30% to 70% RH |
| Max. altitude: | 2000 m / 6562 ft |
| Electrical | |
| Power supply: | 110-240 V~ 50/60 Hz |
| Power consumption: | < 1.5 W |
| External protection: | 16A, tripping characteristic B or C, 6 kA interrupting rating, energy limiting class 3 |
| Max. switching voltage: | 240 V~ |
| Max. switching current: | 13 A |
| Max. control current: | 35 mA |
| Voltmeter (AC): | 110 – 240 V |
| Ammeter (AC): | 50 mA – 16 A |
| Meters accuracy: | ±10% |
| Power and energy meters: | Active and apparent power/Active and apparent energy |
| Power factor | |
| Measurement data storage: | No |
| Internal-temperature sensor: | Yes |
| Wi-Fi | |
| Protocol: | 802.11 b/g/n |
| RF band: | 2401-2495 MHz |
| Max. RF power: | < 20 dBm |
| Range: | Up to 30 m / 100 ft indoors and up to 50 m / 160 ft outdoors (depending on local conditions) |
| Bluetooth | |
| Protocol: | 4.2 |
| RF band: | 2400-2483.5 MHz |
| Max. RF power: | < 4 dBm |
| Range: | Up to 30 m / 100 ft outdoors, up to 10 m / 33 ft indoors (depending on local conditions) |
| Microcontroller unit | |
| CPU: | Shelly ESP32 C3 |
| Clock frequency: | 40 Mhz |
| Flash: | 8MB |
| Microcontroller unit | |
| Schedules: | 20 |
| Webhooks (URL actions): | 20 with 5 URLs per hook |
| Scripting: | Yes |
| MQTT: | Yes |
| Advanced schedules: | Yes |
| KVS (Key-Value Store): | Yes |
