شيلي UNI

Available

Functionalities

POWER
Power supply AC	12V – 24V
Power supply DC	12V – 36V
SPECIAL FUNCTIONS
Inputs	2 Separated digital inputs from 2.2-36V DC and 12-24V AC
Outputs	2 Potential free outputs up to 24VAC and 36VDC, max 100 mA, 300mW each
Overload protection	No
Power measurement	1 ADC – dual ranges from 0-12V and 0-30V
FEATURES
Channels	2 Channels
Operational temperature	0 to + 40 °C
Device power consumption	< 1 W
Intelligent On/Off	Yes
Sunrise/Sunset	Yes
Weekly Schedule	Yes
UL Listed option	No
CONNECTIVITY
Wireless/WiFi Protocol	802.11 b/g/n
Radiofrequency	2400 – 2500 MHz
Range	up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
DIMENSIONS
Size	20mm x 33mm x 13mm
